POWER FORKLIFT FEATURES
The POWER 3 Ton Comfort forklift truck has the same characteristics as the Basic model, in addition to:
Multi-function armrest with fingertip control
Seat with full suspension
Mast with full free double lifting cylinders
Curve speed adjustment to improve stability and reduce risk of overturning
Brake assist when it detects that the operator is releasing the brake on a ramp or slope
Limitation of the front tilt angle to reduce the risk of load drop
When the load exceeds 10% of the set weight, the engine stops working for safety’s sake
Multifunction TFT display with scrolling speed, remaining battery capacity, clock with working hours and accumulated hours, and three speed modes
CPD-30 Electric Forklift Parameters
| Characteristic | |||
| Model | CPD-30B | CPD-30C | CPD-30D |
| Rated Capacity | 3000KG | 3000KG | 3000KG |
| Load Center Distance | 500mm | 500mm | 500mm |
| Power Mode | Lithium & lead-acid batteries | Lithium & lead-acid batteries | Lithium & lead-acid batteries |
| Wheelbase | 1750mm | 1850mm | 1850mm |
| Performance | |||
| Travel speed, laden/unladen | 11/12(KM/H) | 10/10(KM/H) | 10/10(KM/H) |
| Lifting speed, laden/unladen | 280/350(MM/S) | 200/300(MM/S) | 200/300(MM/S) |
| Lowering speed, laden/unladen | 450(MM/S) | 450(MM/S) | 450(MM/S) |
| Battery voltage/ nominal capacity | 80V/300/350/400Ah | 72V/260Ah | 72V/260Ah |
| Battery weight | 830KG | 430KG | 430KG |
| Weight | |||
| Service mass (With battery) | 4150 KG | 4150 KG | 4150 KG |
| Alex load: unload, front/rear | / | / | / |
| Alex load: load, front/rear | / | / | / |
| Maximum negoniable gradient, laden/unladen | 12/15% | 12/20% | 12/15% |
| Electrical configuration | |||
| Drive motor power-60 minutes | 11PMSM/KW | 9PMSM/KW | 9PMSM/KW |
| Lift motor power-15 minutes | 12PMSM/KW | 7.5PMSM/KW | 7.5PMSM/KW |
| Drive motor controlling mode | MOSFET/AC | MOSFET/AC | MOSFET/AC |
| Lifting motor controlling mode | MOSFET/AC | MOSFET/AC | MOSFET/AC |
| Service brake/Parking brake | Hydraulic /Mechanial | Hydraulic /Mechanial | Hydraulic /Mechanial |
| Tyre | |||
| Tyre type | Pneumatic tire | Pneumatic tire | Pneumatic tire |
| Wheels number (front/rear) | 2/2 | 2/2 | 2/2 |
| Front track | 1000mm | 1000mm | 1000mm |
| Rear track | 994mm | 994mm | 994mm |
| Tyre (front) | 28*9-15 | 28*9-15 | 28*9-15 |
| Tyre(rear) | 18*7-8 | 18*7-8 | 18*7-8 |
| Size | |||
| Front overhang | 467mm | 467mm | 467mm |
| Tilt of the mast, front/rear | 5/10° | 5/10° | 5/10° |
| Height, mast retraction | 2057mm | 2057mm | 2057mm |
| Free lift height | 120mm | 120mm | 120mm |
| Overall maximum lift height | 3000mm | 3000mm | 3000mm |
| Height, mast extended | 4200mm | 4200mm | 4200mm |
| Overhead guard height | 2200mm | 2200mm | 2200mm |
| Lateral Fork Adjustment (Outside of Forks) Max/Min | 1100/244mm | 1100/244mm | 1100/244mm |
| Fork size (LxWxT) | 45*122*1070mm | 45*122*1070mm | 45*122*1070mm |
| Truck body length (fork excluded) | 2680mm | 2680mm | 2680mm |
| Truck body width | 1160mm | 1160mm | 1160mm |
| Turning radius | 2370mm | 2370mm | 2370mm |
| Groubd clearance under mast | 82mm | 82mm | 82mm |
| Ground clearance at center of wheelbase (laden) | 145mm | 145mm | 145mm |
| Width of aisle right-angle stacking (pallet1000x1000mm clearance 200mm) | 4100mm | 4100mm | 4100mm |
| Width of aisle right-angle stacking (pallet1200x1200mm clearance 200mm) | 4300mm | 4300mm | 4300mm |
| *The company reserves the right to change product design and specifications without notice. | |||
CPD-30 Electric Forklift Mast Parameter Table
| Gantry
form |
3T/3.5T | ||||||||||
| Total height | Free lifting height | Gantry inclination | Rated load | ||||||||
| Gantry
model |
Maximumlifting
height |
Gantry static
height |
Rack rack | Shelves
without shelves |
Rack rack | Shelves
without shelves |
Front | Rear | Load center distance 500 | ||
| Two wide view gantry | mm | mm | mm | mm | mm | mm | mm | 3 | 3.5 | ||
| M200 | 2000 | 1786 | 3652 | 3297 | 120 | 120 | 5 | 10 | 3000 | 3500 | |
| M250 | 2500 | 2080 | 4152 | 3797 | 120 | 120 | 5 | 10 | 3000 | 3500 | |
| M300 | 3000 | 2230 | 4452 | 4097 | 120 | 120 | 5 | 10 | 3000 | 3500 | |
| M350 | 3500 | 2330 | 4652 | 4297 | 120 | 120 | 5 | 10 | 3000 | 3500 | |
| M400 | 4000 | 2630 | 5152 | 5097 | 120 | 120 | 5 | 6 | 2800 | 3250 | |
| M450 | 4500 | 2880 | 5652 | 5297 | 120 | 120 | 5 | 6 | 2500 | 2850 | |
| Two-stage fully free gantry | U250 | 2500 | 1936 | 3652 | 3247 | 1089 | 1089 | 5 | 10 | 3000 | 3500 |
| U300 | 3000 | 2195 | 4152 | 3747 | 1299 | 1299 | 5 | 10 | 3000 | 3500 | |
| U370 | 3700 | 2495 | 4752 | 4347 | 1608 | 1608 | 5 | 10 | 2800 | 3250 | |
| U430 | 4300 | 2095 | 5452 | 5083 | 1268 | 1268 | 5 | 6 | 2550 | 2850 | |
| Three stage fully free gantry | N450 | 4500 | 2152 | 5652 | 5283 | 1348 | 1348 | 5 | 6 | 2400 | 2750 |
| N480 | 4800 | 2252 | 5952 | 5583 | 1448 | 1448 | 5 | 6 | 2250 | 2450 | |
| N500 | 5000 | 2395 | 6152 | 5783 | 1514 | 1514 | 5 | 6 | 2100 | 2300 | |
| N550 | 5500 | 2630 | 6652 | 6283 | 1678 | 1678 | 3 | 6 | 1650 | 1800 | |
| N600 | 6000 | 2865 | 7152 | 6783 | 1844 | 1844 | 3 | 3 | 1200 | 1300 | |
| N650 | 6500 | 3098 | 7652 | 7283 | 2072 | 2072 | 3 | 3 | 900 | 1000 | |
| Reduced load rating by 130 kg for all added sideshifts | |||||||||||
CPD-30 Electric Forklift Options List
POWER Product Advantages & Picture Details
Suitable for various voltages and industrial waterproof plugs and socket
Accessories for various working conditions
